SWM1507A CNC External Thread Grinder is a high-precision CNC thread grinding equipment for external thread finishing. With mineral casting rigid bed and professional CNC control system, it realizes stable, high-precision batch manufacturing of various complex threaded shafts.

Machine Body Structure & Accuracy Guarantee

Integrated machine base and bed with mineral casting construction, effectively reduces equipment vibration during operation and delivers ultra-high dimensional stability and machining precision for thread workpieces.

Wide Machining Scope of External Threads

Specially developed for external thread grinding on multiple precision components, covering ball screws, worm shafts, rolling dies, and automotive steering core parts, meeting diverse industrial thread processing demands.

Key Thread Machining Technical Parameters

Maximum grinding helix angle: ±30°
Supports multi-start thread grinding
Minimum controllable thread pitch: 0.3mmHigh flexibility for large lead angle and special screw thread production.

Intelligent Compensation Technology

Equipped with automatic grinding wheel wear compensation function, it automatically offsets wheel abrasion in continuous mass production, avoids frequent manual correction, and keeps uniform thread tolerance and surface roughness in long-term processing.

Automatic dressing for wheel	Motor spindle of grinding wheel
Grinding screw with big helix angle	Steady rest for support long workpiece

Item		Unit	SWM1507A	SWM1510A	SWM1520A	SWM1530A
Capacity	Max. grinding thread length	mm	650	1000	2000	3000
	Max. grinding diameter	mm	200	200	200	150
	Max.distance between center	mm	780	1200	2200	3200
	Grinding helix angle		±30°
Machining accuracy	Pitch deviation	mm	0.004
Machining accuracy	Thread surface roughness	μm	0.32
wheelhead	Grinding wheel size(ODxTHxlD)	mm	Φ500/10-25/Φ305
	Spindle speed	min-1	50-3000
	Motor power	kw	7.5	7.5	7.5	15
wheel dresser	Dressing wheel size(ODxTHxlD)	mm	Φ100xΦ25x30
wheel dresser	Max.spindle speed	rpm	6000
Headstock	spindle speed	rpm	0～100
Headstock	motor power	kw	10.35	10.35	10.35	5
X/Z axis	travel	mm	350/950	350/1200	350/2250	150/3300 (linear motor)
X/Z axis	mini. feed	mm	0.001
Other	Machine weight	T	10.5	12	17	26
Other	Machine size(L/W/H)	mm	3500/3300/3000	4000/3300/3000	6200/3300/3000	620033003000

Item		Unit	SWM1507A	SWM1510A	SWM1520A	SWM1530A
Capacity	Max. grinding thread length	mm	650	1000	2000	3000
	Max. grinding diameter	mm	200	200	200	150
	Max.distance between center	mm	780	1200	2200	3200
	Grinding helix angle		±30°
Machining accuracy	Pitch deviation	mm	0.004
Machining accuracy	Thread surface roughness	μm	0.32
wheelhead	Grinding wheel size(ODxTHxlD)	mm	Φ500/10-25/Φ305
	Spindle speed	min-1	50-3000
	Motor power	kw	7.5	7.5	7.5	15
wheel dresser	Dressing wheel size(ODxTHxlD)	mm	Φ100xΦ25x30
wheel dresser	Max.spindle speed	rpm	6000
Headstock	spindle speed	rpm	0～100
Headstock	motor power	kw	10.35	10.35	10.35	5
X/Z axis	travel	mm	350/950	350/1200	350/2250	150/3300 (linear motor)
X/Z axis	mini. feed	mm	0.001
Other	Machine weight	T	10.5	12	17	26
Other	Machine size(L/W/H)	mm	3500/3300/3000	4000/3300/3000	6200/3300/3000	620033003000
