Product classification: MINJIA MACHINE| JIANYE MACHINE|

Product Center

SWM1505/1510/
1520

CNC External Thread Grinder

1. The machine adopt T type mineral casting frame.
2. The machine grinding wheel can finish external thread with V and trapezoid thread type,such as ball screw ,worm,rolling tool,steering component.
3.Turntable set up lead angle A-axis ±25 with automatic , in addition ,optional lead angle ±90 for grinding large angel and pitch thread (SWM1510A)
4. Wearing capacity with automatic compensation(grinding amount 0.01-0.02mm for one time)

SMK204

CNC Internal Thread Grinder

1. Grinding ball nut of cylindrical surface, ending surface and Internal thread race for once clamping.
2.T type natural granite
3.Nuts raceway grinding wheel have two dressing way: Profile and Dish diamond dressing. Excircle grinding wheel dress by diamond pen dresser.
4.The machine can check nut circular hole , automatic ensure location of grinding internal thread.

WNM1505

CNC complex grinder center

1.This machine can grind cylindrical ,inner hole ,thread for complex precision workpiece.
2.4- station hydraulic turntable can change 4 type grinding wheel automatically.

AM850F- 6/8/12/16

Multi-spindle Vertical Machine Center

1.The machine can drill and mill with 6/8/12/16 spindles at the same working time(optional taping function).
2.Customized fixture for workpiece.
3.Gantry-type structure,X axis with large travel.

HF301

Turn-Mill machine

1.Motor spindle move by X/Z axis,let the machine more rigidity.
2.Using gang tool post, but also add power head.
3.Suitable Turning ,drilling and milling for dis type.

HF302

Turn-Mill Center

1.Double motor spindles,the wrokpiece can butt and butt.
2.Using double gang tool post, also add power head.
3.Hydraulic break device to ensure to spindle lock when heavy cutting and milling .
4.Suitable for heavy turning,milling,drilling and tapping process for dis type.

HF402

Double spindle Turn-Mill Center

1.High rigid "T "structure bed.
2.Two axis move by the linear guideway.
3.Two spindles are respectively controlled and do not affect each other.

AMK202/203/204

CNC Complex Grinder

1.Natural granite bed improve manufacturing accuracy.
2.Customized clamping with workpiece.
3.When dresser finish the grinding wheel dressing ,wheel allowance and offset automatically.

Why Choice Us

Machine solution

●Follow the drawing to make new machining solution to reduce product cost.
● Automatic line design for equipment to improve manufacturing efficiency.

Professional service

●It is leading position about machining ball screw and nut, compressor component.
● Conducting of training centers and after service team for oversea.
●Production of sample parts and customized work parts.

News

Industry News

About our team

JIANYE GROUP CO.,LTD is the one oversea marketing platform of GUANGZHOU MINJIA MANUFACTURING TECHNOLOGY CO.,LTD.

Minjia manufacture establish in 2001 in Guangzhou,China, it is about 300 employees, 80% of the above technical secondary school education.

Own property rights and core technologies, with nearly 100 national patents.

Our advantage

0
Machine Design National Patent
0
Compressor part machining solution
0
Own Rolling industry China market
0
CNC Grinder show room in Germany
